Results:

Mfr. Part #	Availability	Quantity	Datasheet	Packaging	Series	ProductStatus	Type	Voltage-Primary	Voltage-Secondary(FullLoad)	Current-Output(Max)	PrimaryWinding(s)	SecondaryWinding(s)	CenterTap	Power-Max	MountingType	TerminationStyle	Size/Dimension	Height-Seated(Max)	Voltage-Isolation
BV030-7274.0 PWR XFMR LAMINATED 1.2VA TH Pulse Electronics Power	2,015	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 6V, Series 12V	Parallel 200mA, Series 100mA	Single	Dual	No	1.2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	24.00mm	-
BV030-7275.0 PWR XFMR LAMINATED 1.2VA TH Pulse Electronics Power	2,030	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 9V, Series 18V	Parallel 132mA, Series 66mA	Single	Dual	No	1.2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	24.00mm	-
BV030-7276.0 PWR XFMR LAMINATED 1.2VA TH Pulse Electronics Power	2,106	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 12V, Series 24V	Parallel 100mA, Series 50mA	Single	Dual	No	1.2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	24.00mm	-
BV030-7277.0 PWR XFMR LAMINATED 1.2VA TH Pulse Electronics Power	2,439	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 15V, Series 30V	Parallel 80mA, Series 40mA	Single	Dual	No	1.2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	24.00mm	-
BV030-7278.0 PWR XFMR LAMINATED 1.2VA TH Pulse Electronics Power	3,878	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 18V, Series 36V	Parallel 66mA, Series 33mA	Single	Dual	No	1.2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	24.00mm	-
BV030-7292.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	2,071	RFQ	Datasheet	-	-	Obsolete	Laminated Core	115V	6V	333mA	Single	Single	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7293.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	2,724	RFQ	Datasheet	-	-	Obsolete	Laminated Core	115V	9V	222mA	Single	Single	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7294.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	3,406	RFQ	Datasheet	Tube	-	Obsolete	Laminated Core	115V	12V	122mA	Single	Single	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7298.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	2,857	RFQ	Datasheet	-	-	Obsolete	Laminated Core	115V	Parallel 6V, Series 12V	Parallel 332mA, Series 166mA	Single	Dual	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7299.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	2,068	RFQ	Datasheet	-	-	Obsolete	Laminated Core	115V	Parallel 9V, Series 18V	Parallel 222mA, Series 111mA	Single	Dual	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7300.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	3,767	RFQ	Datasheet	-	-	Obsolete	Laminated Core	115V	Parallel 12V, Series 24V	Parallel 166mA, Series 83mA	Single	Dual	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7304.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	2,630	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	6V	333mA	Single	Single	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7306.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	3,853	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	12V	166mA	Single	Single	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7307.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	3,371	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	15V	133mA	Single	Single	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7309.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	3,299	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	24V	83mA	Single	Single	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7310.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	2,380	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 6V, Series 12V	Parallel 332mA, Series 166mA	Single	Dual	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7311.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	2,002	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 9V, Series 18V	Parallel 222mA, Series 111mA	Single	Dual	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7312.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	2,871	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 12V, Series 24V	Parallel 166mA, Series 83mA	Single	Dual	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7313.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	2,351	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 15V, Series 30V	Parallel 132mA, Series 66mA	Single	Dual	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
BV030-7314.0 PWR XFMR LAMINATED 2VA TH Pulse Electronics Power	3,140	RFQ	Datasheet	-	-	Obsolete	Laminated Core	230V	Parallel 18V, Series 36V	Parallel 110mA, Series 55mA	Single	Dual	No	2VA	Through Hole	PC Pin	32.50mm L x 27.50mm W	27.00mm	-
